Radifocus™ Introducer II Standard Kit C

Introducer Sheath

Description

Introducers are intended to be inserted percutaneously into a vessel to facilitate the entire interventional procedure.​

Characteristics

  • Total Integrated Fit (TIF) tip tapering: tapering design at the tip of the sheath and dilator to facilitate smooth penetration
  • Cross-cut hemostasis valve: effectively protects against blood reflux and air aspiration
  • Thin radiopaque sheath with anti-kinking sleeve: for easy catheter handling
  • Snap-on / click-off dilator lock: prevents dilator back-out during insertion and allows one-hand unlocking
  • Wide variety of kit variations providing all elements for quick vessel access: 4 - 11 Fr sheaths, 10 and 25 cm lengths, Surflash or micro puncture metal needle

General specifications

​Sheath length10 cm and 25 cm
Guidewire compatibility0.025" (0.64 mm) or 0.035" (0.89 mm) for 4 Fr
0.038" (0.97 mm) for all other items
0.025" (0.64 mm) or 0.035" (0.89 mm) for 4 Fr
0.038" (0.97 mm) for all other items
PackagingPouch
​C Kit content​Sheath and dilator

Item specifications

​Inner diameter ​Guidewire compatibility ​Sheath length ​
10 cm25 cm
4 Fr0.025" (0.64 mm)​RS*C40G10NR
4 Fr0.035" (0.89 mm)​RS*C40K10NR​RS*C40K25NR
6 Fr0.038" (0.97 mm)RS*C60N10NRRS*C60N25NR
7 Fr0.038" (0.97 mm)RS*C70N10NRRS*C70N25NR
8 Fr0.038" (0.97 mm)RS*C80N10NRRS*C80N25NR
9 Fr0.038" (0.97 mm)RS*C90N10NR
10 Fr0.038" (0.97 mm)RS*C10N10NR
11 Fr0.038" (0.97 mm)RS*C11N10NR

Please quote above item reference codes when placing an order.
