Metacross™ RX

PTA Balloon Dilatation Catheter

Description

Advance your approach to exceptional performance

Metacross RX is a percutaneous transluminal angioplasty (PTA) balloon dilatation catheter for peripheral indications.

Characteristics

​Better handling by design1

Essential improvements in efficiency and control with Rapid Exchange1

  • Enables fast, convenient exchange of devices1
  • Supports the use of short guidewires2

  • Encourages procedural efficiency, reducing potentially fluoroscopy time3 and radiation time2
  • Optimizes control allowing a single operator to perform the procedure2

End-to-end4 performance with less effort4

Better pushability results demonstrated with innovative catheter design4

  • Engineered for maximizing pushability with a well-designed shaft and stiff tapered core wire
  • Effective transition of force from proximal to distal end for efficient lesion crossing

General specifications

​Guidewire compatibility​0.035'' (0.89 mm)
​Balloon material​Nylon
​Balloon folding​Tri-fold (Ø 3.0 mm - 9.0 mm)
Penta-fold (Ø 10.0 mm - 12.0 mm)
​Shaft diameter​Distal: 5.7 Fr (1.9 mm)
Proximal: 3.9Fr (1.3 mm)


Balloon Diameter (mm)
​Nominal Pressure (atm)​Rated Burst Pressure (atm)
​3.00
​10​20
​4.00​10​20
​5.00​10​18
​6.00​8​14
​7.00​8​14
​8.00​8​14
​9.00​8​12
​10.00​8​12
​12.00​812​

Item specifications

Catheter length: 135 cm

​Balloon diameter (mm)

Guiding sheath compa-tibility

Balloon length (mm)

20

40

60

80

100

120

150

200

​3.00

​6 Fr

​BD-L30020CR

BD-L30040CR

BD-L30060CR

BD-L30080CR

BD-L30100CR

BD-L30120CR

BD-L30150CR

BD-L30200CR

​4.00

​6 Fr

​BD-L40020CR

​BD-L40040CR

​BD-L40060CR

​BD-L40080CR

​BD-L40100CR

​BD-L40120CR

​BD-L40150CR

BD-L40200CR

​5.00

​6 Fr

​BD-L50020CR

​BD-L50040CR

​BD-L50060CR

​BD-L50080CR

​BD-L50100CR

​BD-L50120CR

​BD-L50150CR

​BD-L50200CR

​6.00

​6 Fr

​BD-L60020CR

​BD-L60040CR

​BD-L60060CR

​BD-L60080CR

​BD-L60100CR

​BD-L60120CR

​BD-L60150CR

​BD-L60200CR

​7.00

​6 Fr

​BD-L70020CR

​BD-L70040CR

​BD-L70060CR

​BD-L70080CR

​BD-L70100CR

​BD-L70120CR

​BD-L70150CR

​BD-L70200CR

​8.00

​6 Fr

​BD-L80020CR

​BD-L80040CR

​BD-L80060CR

​BD-L80080CR

​—

​​—

​​—

​​—

​9.00

​7 Fr

BD-L90020CR

​BD-L90040CR

​BD-L90060CR

​BD-L90080CR

​​—

​​—

​​—

​​—

​10.00

​7 Fr

​BD-LX0020CR

​BD-LX0040CR

​BD-LX0060CR

​BD-LX0080CR

​​—

​​—

​​—

​​—

​12.00

7 Fr

BD-LX2020CR

​BD-LX2040CR

​—

​​—

​​—

​​—

​​—

​​—

References

1 Safety defined as low incidence of complications (included low fracture rate not correlated with a vascular event). Schulte et al. Misago 2: One year outcomes after implantation of the Misago Self-Expanding nitinol stent in the superficial femoral and popliteal artery of 744 patients. Journal of endovascular therapy 2012: 19: 744-784.
2 Compared to conventional over-the-wire technique. Jahnke T et al. Cardiovasc Intervent Radiol. 2008 Sep-Oct;31(5):854-9. Epub 2007 Aug 21.
Muller-Hulsbeck. Rapid Exchange system – what are the benefits? Leipzig Interventional Course 2010.
4 Compared to conventional over-the-wire systems. Linnemeier T.J. et al. Catheterization and cardiovascular diagnosis 30(1), 11-14.
5 Tested against select over-the-wire competitors. Data on file. Terumo Medical Corporation – METACROSS RX Product Info 20150911
