Surflo™

Winged Infusion Set with Needle Protection

Description


Our Surflo Winged Infusion Sets with Needle Protection incorporate the best of Terumo's needle technology allowing smooth skin penetration and are equipped with a shield cover, Surshield®, designed to minimize the risk for potential needlestick injuries.

As soon as the needle is withdrawn from the vein, the protective shield can be manually placed over the entire needle using a onehanded technique. An audible click confirms the proper activation of the Surshield® safety mechanism. Once covered, the needle stays fixed in the shield and the user can safely dispose of it into a Sharps container or by following local guidelines for the disposal of these type of materials.

To ensure stability and grip during venipuncture, our winged infusion sets are equipped with color-coded (ISO), interlocking wings. The material of the tubing is flexible and free of kinking to encourage a consistent flow rate.

Terumo's Surflo Winged Infusion Sets are not made with DEPH and have no natural rubber latex components.

Preparation

Video instructions





Procedure

Step by step instructions

1

​Preposition the protector over the needle.

Recommendations for use. The images are for illustrative purposes only.
Always consult the product label and instructions for use (IFU) for a complete overview of warnings, cautions and precautions prior to actual use.


2

​Keep protector in position while withdrawing.

3

​Press needle and protector together between thumb and index finger until the cover snaps over the needle.

Item specifications


Reference
Colour
Code
External Diameter of Cannula
Needle
Length
(mm)
Tubing Length (mm)
Dead Spacevol.
(ml)
Unit Box
Shipping Carton
Shelf Life (years)​
 G
mm
​SV*S18NL30
​Pink
​18
​1.2
​19
​300
​0.45
​50
​500
​3
​SV*S19NL30
​Ivory
​19
​1.1
​19
​300
​0.45
​50
​500
​3
​​SV*S21NL09
​Green
21​​0.8
​19
​90
​0.20
​50
​500
​3
​SV*S21NL30
​​Green
​21
​0.8
​19
​300
​0.41
​50
​500
​3
​​SV*S22NL09
​Black
​22
​0.7
​19
​90
​0.20
​50
​500
​3
​SV*S22NL30
​Black
​22
​0.7
​19
​300
​0.41
​50
​500
​3
​​SV*S23NL09
​Blue
​23
​0.6
​19
​90
​0.20
​50
​500
​3
SV*S23NL30Blue
230.6193000.40505003
SV*S25NL30Orange250.5193000.40505003


This product is also available for pharmaceutical professionals. Please visit the Terumo Pharmaceutical Solutions website.
